1. Equipped with a 2-inch color TFT-LCD touch screen; capable of displaying the current voltage, date and time, and channel switch status in real time;
2. Support scheduled opening and scheduled closing functions
3. 8-channel switch output, with each channel's delay time for turning on and off freely adjustable (range: 0~999 seconds);
4. Support cascading sequential control of multiple devices, with automatic detection and setting for cascading
5. Equipped with a built-in clock chip, it can automatically turn on/off each channel based on scheduled settings according to the date and time;
6. Undervoltage and overvoltage protection, with customizable protection values;
7. Equipped with RS232 and RS485 interfaces, it supports cascading and central device control;
8. Rated total output current: 60A, single output current: 30A. 9. The rear panel interface allows for cascading use between devices
10. Power-off memory (data will be automatically saved when the device suddenly powers off)
11. The panel features a lockable button;
12. Protection device: Press the power button regularly to enter the screen protection device;
13. Language: Chinese/English language selection;
14. Output power socket specifications: made of flame-retardant ABS material, with phosphor copper material, and a standard universal socket;
15. Circuit board specifications: double-sided fiberboard, with secondary thickening and thickening treatment for main power supply wiring
16. Power supply specification: Built-in switching power supply, suitable for global voltage AC90-260V 50-60HZ
17. Specification of main cable: 3*4mm² cable, with a total length of 1.5 meters (equipped with power input plug)
18. Actuation type: Self-resetting switch
19. Input power supply: AC100~240V, 50~60Hz
20. Single-channel rated output current: 30A
21. Rated total output current: 60A
22. Sequence control with each step time interval: 1~999s
23. Power output interface: 8-channel intelligent control, 2-channel direct output
24. 1U equipment size: 483x320×45mm
